1.0 Overview
ISOMEC is a high-performance, specification-driven piping isometric software developed specifically for Engineering, Procurement, and Construction (EPC) projects.
Designed to eliminate drafting inefficiencies and manual errors, ISOMEC enables engineers to generate construction-ready isometric drawings with:
- Automated specification compliance
- Intelligent component selection
- Accurate cut-length calculation
- Seamless fabrication integration
By simulating 3D piping layouts onto a structured 2D isometric plane, ISOMEC simplifies complex routing—ensuring speed, accuracy, and full standards compliance across large-scale projects.
2.0 Specification
2.1 AUTOSPEC Integration (Specification Intelligence Engine)
- Catalog creation and maintenance
- Specification management
- Material class definition
- Branch table configuration
- Automatic component selection based on rules
Components such as tees, reducers, valves, and branch connections are selected automatically according to predefined logic.
Business Value: • Eliminates manual selection errors and enforces project-wide standardization.
2.2 Intelligent 3D-to-2D Isometric Drafting
- Simulates 3D piping layout in a structured 2D isometric plane
- Handles:
- Straight runs
- Complex offsets
- Rolled lines
- 2D & 3D skewing
- Clean visual drafting interface for intuitive modelling
Business Value: • Accelerates drafting while preserving geometric accuracy.
2.3 Automated Component & Fitting Insertion
- Auto insertion of bolts and gaskets
- Automatic fitting selection during placement
- Ensures BOM accuracy and visual correctness
Business Value: • Reduces repetitive drafting effort and prevents procurement mismatches.
2.4 Smart Dimensioning & Cut-Length Accuracy
- End-to-end intelligent dimensioning
- Auto-subtraction of fitting dimensions
- Accurate pipe cut-length computation
Business Value: • Delivers fabrication-ready lengths without manual recalculation.
2.5 Advanced Revision Management
- Automatic revision comparison
- Cloud-marking of changes
- BOM auto-updates after modifications
- Reduced rework and change oversight
Business Value: • Ensures controlled engineering change management.
2.6 Fabrication & Construction Integration
- Generates .ipmf files for AUTOSPOOL integration
- Outputs .dwg and .pdf files
- Includes:
- Weld types
- Inch-diameter callouts
- Pipe cut lengths
- Bill of Materials
Business Value: • Enables smooth transition from engineering to spooling and fabrication.
2.7 Construction-Ready Visualization
- Insulation & tracing representation
- Pipe support tagging
- Instrument ballooning
- Field weld marking
- Spool split visualization
- Automatic elevation tracking
Business Value: • Improves clarity for site execution teams.
2.8 Custom Symbol Generator
- Create non-standard graphical symbols
- Add project-specific components directly
Business Value: • Provides flexibility without compromising standards.
2.9 Firefighting System Support
- Dedicated catalog for fire protection systems including:
- Twin elbows
- Tapped tees
- Y-pieces
Business Value: • Simplifies routing of firefighting systems with preloaded logic.
2.10 Engineering Utilities
- Valve sheet generation
- Thickness calculation (ASME / IBR compliant)
- As-built drawing preparation
- Construction-phase revision incorporation
Business Value: • Supports engineering validation and final documentation.
2.11 Advanced BOM & Reporting
- Line-wise BOM
- Overall project BOM
- Excel export capability
- Procurement-ready outputs
Business Value: • Improves coordination between engineering, procurement, and fabrication.
2.12 Multi-User Collaboration
- Concurrent drafting by multiple engineers
- Secure project-based access
- Accelerated large-scale execution
Business Value: • Enhances productivity across multi-discipline teams.
5.0 Enterprise Impact
In large EPC projects, manual drafting can result in:
- Incorrect component selection
- Miscalculated pipe lengths
- Revision confusion
- Fabrication delays
- Procurement mismatches
ISOMEC transforms piping drafting into a specification-driven, automation-led, fabrication-ready digital process – reducing engineering effort while improving downstream execution accuracy.
6.0 Why ISOMEC
- Specification-driven intelligence
- Automated component logic
- Integrated cut-length computation
- Direct spooling compatibility
- Multi-user engineering environment
- Seamless EPCPROMAN ecosystem integration
ISOMEC converts complex piping layouts into intelligent, fabrication-ready isometrics – ensuring speed, precision, and full standards compliance across EPC projects.
